using System.Drawing.Drawing2D;
using DevExpress.XtraGrid.Views.Card;

private void cardView1_CustomDrawCardCaption(object sender, CardCaptionCustomDrawEventArgs e) {
   CardView view = sender as CardView;
   bool isFocused = e.RowHandle == view.FocusedRowHandle;
   // A brush to draw the background of the card caption.
   Brush backBrush;
   if(isFocused)
      backBrush = e.Cache.GetGradientBrush(e.Bounds, Color.LavenderBlush, Color.Navy,
        LinearGradientMode.Vertical);
   else
      backBrush = e.Cache.GetGradientBrush(e.Bounds, Color.Cornsilk, Color.DarkKhaki,
        LinearGradientMode.Vertical);
   // A brush to draw the text.
   Brush foreBrush = isFocused ? Brushes.White : Brushes.Chocolate;
   Rectangle r = e.Bounds;
   // Draw a 3D border.
   ControlPaint.DrawBorder3D(e.Graphics, r, Border3DStyle.RaisedInner);
   r.Inflate(-1, -1);
   // Fill the background.
   e.Graphics.FillRectangle(backBrush, r);
   r.Inflate(-2, 0);
   // Draw the text.
   e.Appearance.DrawString(e.Cache, view.GetCardCaption(e.RowHandle), r, foreBrush);
   // Default painting is not required.
   e.Handled = true;
}

Imports System.Drawing.Drawing2D
Imports DevExpress.XtraGrid.Views.Card

Private Sub CardView1_CustomDrawCardCaption(ByVal sender As Object, _
ByVal e As CardCaptionCustomDrawEventArgs) Handles CardView1.CustomDrawCardCaption
   Dim view As CardView = CType(sender, CardView)
   Dim isFocused As Boolean = e.RowHandle = view.FocusedRowHandle
   ' A brush to draw the background of the card caption.
   Dim backBrush As Brush
   If isFocused Then
      backBrush = e.Cache.GetGradientBrush(e.Bounds, Color.LavenderBlush, Color.Navy, _
        LinearGradientMode.Vertical)
   Else
      backBrush = e.Cache.GetGradientBrush(e.Bounds, Color.Cornsilk, Color.DarkKhaki, _
        LinearGradientMode.Vertical)
   End If
   ' A brush to draw the text.
   Dim foreBrush = IIf(isFocused, Brushes.White, Brushes.Chocolate)
   Dim r As Rectangle = e.Bounds
   ' Draw a 3D border.
   ControlPaint.DrawBorder3D(e.Graphics, r, Border3DStyle.RaisedInner)
   r.Inflate(-1, -1)
   ' Fill the background.
   e.Graphics.FillRectangle(backBrush, r)
   r.Inflate(-2, 0)
   ' Draw the text.
   e.Appearance.DrawString(e.Cache, view.GetCardCaption(e.RowHandle), r, foreBrush)
   ' Default painting is not required.
   e.Handled = True
End Sub
